What can AQUATHERM GREEN do?
aquatherm green has not only revolutionised the plastic piping sector, but has been shaping it for decades. Due to its excellent ecological properties, the innovative all-round talent made of corrosion-resistant polypropylene shows its advantages, especially in the field of drinking water applications. It is completely free of heavy metals and toxic chemicals. aquatherm green is also ideally suited for swimming pools, agriculture, shipbuilding or the transport of potable water, taking into account its chemical resistance. A form-fit and material-fit means a secure connection is created due to the very good welding properties.
What should you know about the technical features of AQUATHERM GREEN?
The diameter of the PP pipe determines its location and intended use. In order to be able to lay a pipeline from the connection to the outlet, the pipe diameter of the individual pipes and fittings must be compatible with each other.
aquatherm green S: Ø 20 - 315 mm
aquatherm green MF: Ø 20 - 32 mm
aquatherm green MF UV: Ø 20 - 32 mm
aquatherm green MF RP: Ø 32 - 315 mm
aquatherm green MF RP UV: Ø 32 - 315 mm
The SDR (Standard Dimension Ratio) is a ratio indicating the resistance to pressure. In order to guarantee a certain pressure resistance, a certain maximum SDR number is necessary, depending on the type of material. The following applies: the greater the wall thickness, the smaller the SDR number and the more pressure-resistant the plastic pipe. The unit indicates the ratio between outer diameter and wall thickness of a pipe. aquatherm blue is available in the following SDR sizes:
SDR 6: aquatherm green S
SDR 7,4: aquatherm green S | aquatherm green MF | aquatherm green MF UV
SDR 9: aquatherm green MF RP | aquatherm green MF RP UV
SDR 11: aquatherm green S
aquatherm polypropylene pipe systems put an end to corrosion damages. All materials are corrosion resistant and show reduced flow noise compared to metallic pipes. aquatherm pipes are impermeable to light. Therefore there is no danger of algae formation.
The systems include all elements for the pipe system installation for chilled, hot fluid and various industrial applications:
• Pipes in straight lengths and / or coils
• Fittings
• Flanged joints
• Water point connections and accessories
• Welding devices and machines
• Weld-in saddles
• Manifolds
• Shut-off devices
• Cutting and peeling tools
• Installation guide and fastenings
• Transition joints from PP to metal or from metal to PP
Questions that customers often ask about AQUATHERM GREEN
You can use aquatherm green for drinking water applications, in swimming pool technology, chemical transport considering the resistance of the material, in shipbuilding.
We offer numerous pipe types. You will find a detailed overview of all variants of aquatherm green in the section product types on this page.
Your aquatherm contact person is at your disposal for further information or concrete project enquiries.
Questions that customers often ask about AQUATHERM GREEN
Where can aquatherm green be used?
Which pipe types are available from aquatherm green?
How can I purchase aquatherm green?
What fire protection solutions are offered for aquatherm green?
The aquatherm polypropylene pipe systems comply with the requirements of the fire classification B2 DIN 4102 (normal inflammable). Compared to natural products like wood, cork or wool, aquatherm polypropylene pipes do not produce any gas toxicity. In case of fire, there is no risk of dioxin emissions.
To avoid fire and smoke transmission aquatherm advises the use of fire retardant seals. The fire resistance period is the minimum period in minutes. The extent of the preventive measures depends on the type of installation. The determining of fire areas and fire classification has to be made in accordance with the law of the country. Information is given by the Planning Department and Building Control Office or the Fire Protection Representative.
Basically fire walls and ceilings with pipe passages have to be installed to the same fire resistance classification. All fire protection systems with a corresponding classification are suitable for aquatherm polypropylene pipes.
The following companies offer suitable fire protection solutions:
Brandschutzrohrschale
Conlit 150 U:
DEUTSCHE ROCKWOOL
GmbH & Co. KG
Rockwool Straße 37-41
45966 Gladbeck
Tel: +49 2043 408 0
www.rockwool.de
Brandschutzmanschette
AWM II:
Flamro Brandschutz
Vertriebs GmbH
Am Sportplatz 2
56291 Leiningen
Tel. +49 6746 9410-0
Mail: info(at)flamro.com
www.flamro.de
Hilti Deutschland AG
Hiltistrasse 2 · 86916 Kaufering
Tel: +49 800 888 · www.hilti.de
Planning:
- TrinkwV-2000 Regulation for Potable Water
- DIN 2000 Central drinking water supply-Guidelines regarding requirements for drinking water, planning, construction,operation and maintenance of plants
- EnEV Decree for Energy Saving
- DIN 1988 Standard for Potable Water Installations
- ISO 10508 Plastic pipe systems for hot and cold water installation – Guideline for classification and dimensioning
- All provided pipe-systems correspond to the technical conditions of the application classes acc. to ISO 10508 for the field of potabel water and heating. aquatherm green pipe for the classes 1, 2 (potable water), aquatherm blue pipe for the classes 4 and 5 (heating).
- For the application of the classification system (acc. to ISO 10508) the national regulations and the manufacturer¢•s instructions must be considered.
- DIN 4109 Standard for the Elimination of Noise in the Field of Structural Engineering
- DIN 18381 Installation of Gas, Water and VOB Part C Sewage Pipes inside Buildings
- DIN 16928 Pipe Connections, Fittings, Installation
- DVS 2207 Welding of Thermoplastics
- DVS 2208 Welding Machines and Devices for Thermoplastics
Systemspecific standards:
- General quality requirements, dimensions
- DIN 8077 Polypropylene (PP) Pipes, Dimensions
- DIN 8078 Polypropylene (PP) Pipes, General Quality Requirements
- DIN 16962ff Pipe Joint Assemblies and Fittings for Polypropylene Pressure Pipes
- DIN EN ISO 15874ff Plastic pipe systems for hot and cold water installation; polypropylene
- DVGW-Working sheets
- SKZ-Guidelines
- DIN EN ISO 9000 ff.
Systemspecific standards: Hygiene
BfR Federal Institute for risk assignment
- Health assessment of plastics and non-metallic materials within the framework of the law for foods and commodity goods for potable water applications
DVGW-working sheet W 270
- Increase of Microorganism on Materials. Used for Potable Water Applications – Test and Evaluation BS 6920
- “Suitability of non-metallic products for use in contact with water intended for human consumption with regard to their effect on the quality of water.”
- Local regulations and codes of practice must be observed. The same goes for regulations regarding the use of chemicals.
- *(Additional regional decrees and recommendations are disregarded.)
aquatherm polypropylene pipes may be stored outside at any temperature. A solid base for the pipe is very important to avoid a deformation of the pipes while in transport and storage.
At temperatures below 0 °C it is possible to damage the pipes through strong impacts. The material has to be treated with caution at low temperatures. In spite of its high resistance aquatherm pipes should be treated with care. UV-radiation has effects on all high polymer plastics. Do not store permanently outdoor. The maximum permissible storage time outdoors is 6 months.
